Aggressive appearance
Increased ground clearance
HD 0.25" thick crossmember
Lower control arms feature high clearance design
Front adjustable track bar is made of forged solid steel for unsurpassed strength and durability
Extreme travel long arms keep optimum alignment and give optimum articulation.
X-Flex control arm features:
Clevite brand OEM style rubber bushings.
Flex joints are fully rebuildable.
Flex joints feature a massive 2.5" diameter body and 1.25" thread.
Fully greasable.
Adjustable retainer ring.
Upper joints pivot up to 20 degrees.
Lower joints pivot up to 35 degrees.
Notes - IMPORTANT
Does NOT fit AWD models.
Transfer case skid plate will NOT fit models equipped with 249 transfer case.
Exhaust will have to be cut and rerouted to make sure it is away from the moving components.
Models equipped with a CV style front driveshaft may result in driveshaft vibration. If this occurs, replacing the driveshaft, axle yoke and / or transfer case yoke will need to be performed to rid the vehicle of driveline vibration.
